009

Wanhao i3 Z-axis bearing block

Since extending the Z-axis on my wanhao i3 printer I discovered that there was a small amount of ringing toward the middle of the axis when printing at high speeds. To alleviate this I decided to use the feed screw to provide extra support. I did this by putting a small bearing block at the…

003

WANHAO Duplicator i3 Z-Axis extension

WANHAO Duplicator i3 Z-Axis extension Decided to extend the Z axis on my Wanhao i3 printer as it was wanting to print some rather tall teardrop lampshades. The whole process is very simple and only requires about $40 worth of parts, you will need: 1.5 meters of 60 x 3mm equal mill aluminium angle. This…

009-2

Verge-and-folio 3D printable Clock

This mechanical weight clock has been designed with ease of printing and construction in mind. The design uses a minimum of specialized parts, requiring just 2x paper clips, 4x 12mm countersunk head timber screws, some epoxy glue, 4x M20 stuctural nuts and 9x M14 nuts. All other parts are printed. All the gear and mechanical…

013

3D Printed Direct Current Electric Motor

This basic direct current electric motor has been designed with simplicity and ease of construct in mind, as such there are a minimum of parts and requires no soldering. This makes it an ideal classroom or children’s project.   The project consists of only 3 printed parts, four 2x10mm neodymium magnets, 2 C cell batteries…

004

Wanhao Duplicator i3 Y-Axis extension

So i went shopping in ALDI a little while ago and ended up coming home with a 3D printer and a bunch of other impulse items. The Cocoon Create 3D printer is actually just a re-badged Wanhao Duplicator i3 which is a very popular entry level printer with a huge online community. However after using…

002

Chickens and Other Living Stuff

A few spring showers and cooler weather this year meant that the garden picked up nicely, there is still a huge amount of work to do removing the nutgrass lawn and installing an irrigation system for the orchard, but it will happen. Trying to get the belgian d’uccle back into the hutch, she is a fast…

001

Restoring the Cosmos Valve Amplifier

A few months ago I spotted a very interesting and attractive looking valve amplifier on gumtree that I couldn’t resist. The amplifier was being sold for repair or parts as one of the valves was red-plating leaving one channel dead. This really didn’t phase me as troubleshooting valve gear is pretty straight forward, and red…

004 (30)

Setting up a planted aquarium

A few months ago I had the idea to drag my old aquarium out of storage, it had been stored away after my original fish died from old age (6 years is not bad for a goldfish). The aquarium base had been a quick job that I had made out of scrap timber from an…

004 (10)

Fixing an old electric synchronous clock

Some years ago I found what I thought was a very cool electric clock in an opp shop. It was 240 volt powered and had rotating numbers as opposed to the usual flip down numbers. Upon getting it home I realized that the mechanism had seized, after disassembling the little geared engine assembly and re-lubricating…
